How to get connected to a Database and work with it via ADO and FireDAC

The difference between working with databases using the ADO technology and the FireDAC library

Publish date:
Discover more of what matters to you

From this article, you will learn the difference between working with databases via the ADO technology and the FireDAC library.

  • ADO (ActiveX Data Objects) is an app programming interface developed by Microsoft and based on the component technology ActiveX. ADO allows providing data from different sources (relational databases, text files, etc.) in an object-oriented format.
  • FireDAC is a universal data access library that is intended for developing apps for different devices that should be connected to corporate databases. Thanks to a universal and highly-effective architecture, FireDAC ensures high-speed direct native access from Delphi and C++Builder to InterBase, SQLite, MySQL, SQL Server, Oracle, PostgreSQL, DB2, SQL Anywhere, Advantage DB, Firebird, Access, Informix, etc.

It’s important to understand that FireDAC is a library. At the same time, ADO is a global technology that ensures access not only to databases but also to texts, documents, tables, and others.

In this article, we will consider the connection to MS Access and SQLite databases using both technologies, conduct data sampling and display them on the grid.

CoConnection to MS Access databases via ADO

To get connected to the MS Access database we need to add a TADOConnection component to the form and tune it.

For setting the connection we can move to the ConnectionString property in the object inspector and press the button with three dots “…” or make a double-click on the component.

We will see a form where it will be required to choose an option Use Connection String and press a Build button.

form where it will be required to choose an option Use Connection String and press a Build button

In the next form, it is necessary to choose Microsoft Jet 4.0 OLE DB Provider and press Next >>

Microsoft Jet 4.0 OLE DB Provider

We will get to the next tab “Connection”. Here we need to indicate the path to the database file and click OK.

tab “Connection”

Then we need to click OK once again in the window where you can see our Connection String

window where you can see our Connection String

We have only one step left. In the Object Inspector window, it is necessary to switch the LoginPrompt property to False so that after connecting to the database we won’t get a window for inserting login and password.

the Object Inspector window

If everything is set correctly, we are able to add the Connected property to True and our component will connect to the database. But we won’t do that. The best practice is to get connected to a database during the program launch. For doing that, we can make a double-click on the form and open a code editor where we will see a procedure for a form creation event and add there one code line as you can see in the screenshot below.

code editor

Then we need to add a TADOQuery component to the form and make all the settings. First of all, we need to set the Connection property. In order to do it, from the dropdown list we need to choose ADOConnection1 which has been set at the previous steps.

dropdown list

Now in the SQL property, we will set a question for data sampling.

SQL property

After that let’s go back to the code editor and continue writing our code for the form creation procedure.

code editor

After setting Connected in True we should check whether everything is okay with our connection and execute our inquiry.

Now it is necessary to insert our data into the form. We will use the TDBGrid component. Let’s place it onto the form and choose the Align property in alClient in order to place it on the entire form.

form

Everything is almost ready for displaying our data. There is only one thing left. To link data in the dataset (ADOQuery1) with the grid we need to add the TDataSource component and indicate ADOQuery1 in its DataSet property and then go to the grid parameters and indicate DataSource1 in the DataSource.

Now we can start our app.

app

As you can see in the screenshot above, when the program was started it got connected to the database, opened the data set, and using the data source, displayed the content in the grid.

Connection to an SQLite Database via ADO

The next task that we will fulfill is the connection to an SQLite database using the ADO technology.

We will need the same component set that’s why we offer to continue working with an app, changing just the way of getting connected to a database.

But before we proceed to settings we need to install a provider for SQLite databases into the system. You can download it following the link.

Now we need to come back to settings. Again let’s open the ConnectionString property of the ADOConnection1 component for editing. Now let’s choose another provider. It will be the Microsoft OLE DB Provider for ODBC Drivers.

Microsoft OLE DB Provider for ODBC Drivers

Now our window “Connection” for connection property editing looks a little bit different.

window “Connection”

Here we need to indicate a data source. In the dropdown list, we can see only SQLite3 Datasource that doesn’t refer to data.

Now it is necessary to add our source to the system. For doing that we need to open a system window ODBC Data Sources that is shown below.

system window ODBC Data Sources

Let’s press the Add button, find the necessary SQLite3 ODBC Driver button and press the Finish button.

SQLite3 ODBC Driver button

Now we see a setting window for the chosen driver.

setting window for the chosen driver

Here it is important to indicate the name of the data source and the path to the database. After pressing OK we will see that our data source is now displayed on our list.

data source

Let’s press OK again.

Now let’s make sure that the source is available to us from Delphi. In order to do it, in the window with connection properties we need to press the Refresh button and check the list.

window with connection properties

We see that our SQLite Demo source has appeared there. We need to choose it and confirm our choice by pressing OK. We can see now that the connection row has changed.

SQLite Demo source

Now we should start our app again and we will see that the app is working just the same way.

app

It’s worth mentioning that we have used the databases that were provided by the Embarcadero company together with code samples, that’s why despite the fact that we have got connected to different databases, they contain identical data.

Connection to an MS Access Database via FireDAC

Now we will try to repeat all our actions and to get connected to the same databases but now using FireDAC.

Let’s continue using our app and fulfill a small preparation. We need to delete the  ADOConnection1 and ADOQuery1 components from the form as well as the code that we wrote for connecting with databases.

Now we can proceed directly to the connection setting with FireDAC.

Let’s add the TFDConnection component to the form, make a double-click and move to settings. In the form that will be opened let’s choose MSAcc from the Driver ID dropdown list and then indicate the path to the database in the Database parameter (highlighted with yellow in the screenshot)

Database parameter

Let’s save the settings and set the LoginPromt property with the value False as we’ve done in the case of ADO.

settings

The next step will be to add a TFDQuery component to the form. It’s worth mentioning that in this case, the Connection property of the component will be automatically filled in with the value FDConnection1. If it doesn’t happen, it is necessary to do it manually.

Now with the help of a double-click, we need to open a window for editing an inquiry and insert the necessary one. Using the Execute button, we can check the correctness.

window for editing

In order to fully finish our preparations, it is necessary to indicate our FDQuery1 in the DataSet property of the DataSource1 component that we have in the form.

FDQuery1 in the DataSet property of the DataSource1

In order to start our app and to get the data displayed, we need to add a code for creating a form, connecting to a database and opening a dataset.

code for creating a form

If we start the program, we will see the same parameters.

program

Connection to an SQLite database via FireDAC

Let’s have a look at the method that allows us to get connected to an SQLite database using the same FireDAC. Let’s continue the app modification. Now we need to open the database connection window once again by making a double-click on a FDConnection1 component and to change the Driver ID to SQLite. The list of parameters now differs. Again, we need to indicate the path to a database in the database parameter.

list of parameters

Now we can start the app again. Everything is working correctly.

If you have fulfilled all the steps that are described in this article and managed to get connected to different databases via ADO and FireDAC, you may have noticed that it was significantly easier to do that with FireDAC. It is enough just to place a component into the form, choose the necessary driver from  RAD Studio and indicate the necessary parameters for the connection. Work with data via ADO requires additional settings in the system as well as the support of the technology from the side of the operating system.

In programming, developers may have different tasks that’s why skills of working with different technologies are an important advantage. But which of them to use in this or that case is up to you to decide.

We’d also like to add that as RAD Studio supports the creation of cross-platform apps, the use of such a powerful in-built tool as FireDAC will be rather convenient.
