How to use FMX dialogs correctly in Delphi apps

Delphi FMX provides support for customized native dialog boxes (like those used for confirmations and warnings), available in all supported target platforms. Understanding how these dialogs work is important not only for everyday development but also during larger initiatives like software modernization or Delphi migration, where UI consistency and cross-platform behavior must be carefully reviewed. This article will show the basics and the rules of how to use these dialogs correctly in your Delphi FMX apps.

What dialogs are available?

There are 3 kinds of native dialogs available by FMX in every OS:

• MessageDialog: a dialog box in a special kind (Error, Confirmation, Information, Warning). It contains text and a custom set of buttons, every button returning a response as an integer to the calling app.
• InputQuery: a dialog box that contains a custom number of text input fields (TEdit controls). This dialog will return an array of strings to the calling app.
• ShowMessage: a simpler dialog box, used only for information with a text and an “OK” button. Nothing is returned to the calling app.

Basics of FMX dialogs

Dialog behavior

According to the platform, dialogs can have two different behaviors:

• Synchronous: the app (that called the dialog) is blocked by the called dialog box until it is closed by the user. This behavior is supported on Windows, MacOS and iOS. But it is not supported on Android (because the OS does not support blocking of the app’s main thread).
• Asynchronous: the app is not blocked by the called dialog box; the app remains accessible for user interactions. This behavior is supported on Windows, macOS, iOS and Android.

The methods for calling Sync dialogs are functions that return responses to the executing app, while the methods for calling Async dialogs are procedures containing anonymous methods (with the dialog responses as parameters) that are executed when the dialog is closed.

Both behaviors are implemented in the FMX platform services.

The actual FMX architecture provides two concepts for using these dialogs, you can choose between:

• Using a platform service from the “FMX.Platform” unit, by declaring an instance of the service interface (as a variable) and the “Supports” routine. Those service interfaces are :
  • “IFMXDialogServiceAsync” for Async dialogs and,
  • “IFMXDialogServiceSync” for Sync dialogs.
• Or, using the helper class that provides class methods and functions for calling the dialog boxes without the need for an instance of the corresponding dialog box platform service. Those helper classes are :
  • “TDialogServiceAsync” (by using the unit “FMX.DialogService.Async”) and,
  • “TDialogServiceSync” (by using the unit “FMX.DialogService.Sync”).

Dialog type

For the kind of “MessageDialog”, you have to define the type of your dialog box, which will affect its appearance. Mostly the title of the dialog box (which is localized to the underlying OS language).

The type of the dialog box is set by a value of “TMsgDlgType”:

TMsgDlgType = (mtWarning, mtError, mtInformation, mtConfirmation, mtCustom);

Value	Meaning	Dialog box title
mtWarning	Warns the user about a potential issue.	Warning
mtError	Informs the user of an error that occurred.	Error
mtInformation	Provides information to the user.	Information
mtConfirmation	Ask the user for confirmation.	Confirm
mtCustom	None of the above.	Your project name

Dialog box buttons

Especially for the “MessageDialog”, you can choose a set of buttons (their type is “TMsgDlgBtn”) to appear at the bottom of the MessageDialog. Also, the caption on these buttons is localized according to the OS language.

Each of these buttons, when clicked, will close the dialog box and return a corresponding integer value as “TModalResult”. Because, in fact, the dialog box is a modal form and setting the value of its TModalResult property to a non-zero integer value will close the modal form.

The returned TModalResult value can be used in the caller app, either assigned directly to a variable (in case of Sync dialogs) or in an anonymous method to perform custom actions after closing the dialog box (in case of Async dialogs).

The table below enumerates the MessageDialog buttons and their corresponding returned ModalResult (as named constant and integer):

TMsgDlgBtn value	Corresponding returned value	ModalResult corresponding integer value
mbOK	mrOk	1
mbCancel	mrCancel	2
mbAbort	mrAbort	3
mbRetry	mrRetry	4
mbIgnore	mrIgnore	5
mbYes	mrYes	6
mbNo	mrNo	7
mbClose	mrClose	8
mbHelp	mrHelp	9
mbAll	mrAll	12
mbNoToAll	mrNoToAll	13
mbYesToAll	mrYesToAll	14

Also, the “FMX.Dialogs” unit defines constants that you can use to represent some predefined sets of buttons, as shown in the following table:

mbYesNo	TMsgDlgBtn.mbYes, TMsgDlgBtn.mbNo
mbYesNoCancel	TMsgDlgBtn.mbYes, TMsgDlgBtn.mbNo, TMsgDlgBtn.mbCancel
mbYesAllNoAllCancel	TMsgDlgBtn.mbYes, TMsgDlgBtn.mbYesToAll, TMsgDlgBtn.mbNo, TMsgDlgBtn.mbNoToAll, TMsgDlgBtn.mbCancel
mbOKCancel	TMsgDlgBtn.mbOK, TMsgDlgBtn.mbCancel
mbAbortRetryIgnore	TMsgDlgBtn.mbAbort, TMsgDlgBtn.mbRetry, TMsgDlgBtn.mbIgnore
mbAbortIgnore	TMsgDlgBtn.mbAbort, TMsgDlgBtn.mbIgnore

Usage

Now, let’s see how to use each kind of these native dialogs.

Using the “ShowMessage”

The simplest kind of dialog you only need to specify the text that will be shown.

The code for calling ShowMessage Async:

The code for calling ShowMessage Sync:

Using the “MessageDialog”

As explained in the basics above, for using MessageDialog, you need to specify:

• The message (text of the dialog).
• The dialog type (mtWarning, mtError, mtInformation, mtConfirmation, mtCustom)
• The set of buttons.
• The default button that will have the initial focus when the dialog is shown.
• The help context (0 if no help is used in the app).

For Async MessageDialog, you need, as an additional parameter, an anonymous method to handle the dialog result, like the following code snippet:

But for Sync MessageDialog, the dialog result is returned as an integer from the dialog calling method.

The code for calling MessageDialog Async:

The code for calling MessageDialog Sync:

Using the “InputQuery”

For using InputQuery, you need to specify:

• The caption of the dialog box.
• The prompt of each input field (a declared variable of an array of strings), and if you want to mask a field as a password, add ‘#1’ before the prompt (like #1 + ‘Password’).
• The values of each input field: A declared variable of an array of strings, can be filled at runtime (before calling the dialog) to serve as default values.

For Async InputQuery, you need, as an additional parameter, an anonymous method to handle the dialog result (clicked button) and the user input values, like the following code snippet:

But for Sync InputQuery, the dialog calling function returns a boolean value (true if the user clicked OK button). Then the user input values can be accessed through the Values variable.

The code for calling InputQuery Async:

The code for calling InputQuery Sync:

Conclusion

Like any other component in the Delphi frameworks, knowing the mechanism and the basics behind native dialogs allows the developer to use them correctly and effectively in their projects.
